Features and Benefits
Safety Features
• The bath features a low liquid level float switch. This ensures heating will be switched off if the liquid level falls below the recommended level. The motor and heater are switched off in this instance.
Energy Consumption
0.5kWh @ 37°C
0.4kWh @ 60°C – lid fitted
(Based on NE4-8T)
The lower the figure, the less energy used. Information supplied for size and range comparison, guidance only and measured consumption at set point. Please remember that the energy consumption may vary due to factors such as location, ventilation, ambient temperatures and loading.
Controls
Thermostatic temperature control, providing quick reliable selection and attainment of desired operating temperature. Every unit undergoes a factory calibration at 50°C for validation.
Heating Information
For water temperatures above 60°C we recommend that an accessory lid or layer of spheres are used for optimum performance. This will reduce evaporation and a lid will keep the samples and water free from contamination. Optimum performance saves energy by reducing electricity consumption and running costs.
Stainless Steel Flat Lid
When fitted, this lid prevents contamination of liquid from airborne particles. Can also be useful when a Clifton water bath is ‘in use’, minimising heat loss, saving energy, and assisting to maintain bath temperature ready for the next application. The lid is fitted with an insulated handle.
| Product Code | Bath |
|---|---|
| LD4-8 | NE4-8T |
| LD4-14 | NE4-14T |
| LD4-22 | NE4-22T NE4-28T |
Stainless Steel Gable Lid
Clifton stainless steel gable lids help reduce evaporation, assist in keeping samples in a water bath free from contamination and save energy. These stainless steel gable lids with a high profile allow extended use of the bath, right into the edges of the tank. No drip points to contaminate samples whilst the lid design ensures all condensate returns back into the bath. Insulated handles for safe use.
| Product Code | Bath |
|---|---|
| SL4-8 | NE4-8T |
| SL4-14 | NE4-14T |
| SL4-22 | NE4-28T |
Stainless Steel Test Tube Racks
Laboratory test tube rack, stainless steel 304 spec 18/8 non-magnetic, bright finish. Supplied flat packed ready for assembly. Can be cleaned with detergents, ultrasonics or autoclaved. Durable and stable in use with looped handles for easy retrieval from hot water baths.
• NE4-8T = 1 rack
• NE4-14T = 3 racks
• NE4-22T = 5 racks
• NE4-28T = 5 racks
| Product Code |
|---|
| 6870 - (26 holes x 17mm diameter) |
| 6871 - (16 holes x 26mm diameter) |
| 6872 - (36 holes x 13mm diameter) |
| 6873 - (18 holes x 19mm diameter) |
| 6900 - (12 holes x 32mm diameter) |
Hose Tail Nozzle
The hose tail nozzle attaches to the tap to allow connection for 12mm i.d rubber hose.
| Product Code | |
|---|---|
| BX0952 | NE4-28T |
Drain Tap
Water baths with serial numbers greater than 75100 should order this accessory drain tap BX0953. These fast draining outlets provide a gated on/off valve to empty fluids conveniently from the bath.
| Product Code | Bath |
|---|---|
| BX0953 | NE4-28T |
Stainless Steel Raised Shelves
The raised shelf provides a reduced liquid depth for shallow vessels in NE4 series water baths. Simple solution for placing shallow vessels in a stirred bath. Manufactured from stainless steel. The raised shelf is perforated to allow free circulation of water. Can be easily removed and cleaned.
| Product Code | Bath |
|---|---|
| RS4-14 | NE4-14T NE4-22T NE4-28T |
| RS4-22 | NE4-22T NE4-28T |
Universal Accessories
Bath Armor™ is moisture and gas impermeable, high thermal conductivity, smooth and rounded almost fluid like and reduces your water consumption.
This blanket of hollow spheres is ideal for open tanks of water. Reduces thermal losses – Savings of up to 60% can be achieved with a single layer – Increase energy saving & reducing costs.
| Product Code | Capacity |
|---|---|
| BP0368 : 1 Pack | 8 Litre baths |
| BP0368 : 2 Packs | 14 Litre baths |
| BP0368 : 3 Packs | 22 Litre baths 28 Litre baths |
| BP0368 : 5 Packs | 38 Litre baths |
| BP0368 : 8 Packs | 56 Litre baths |
Allows easy and quick emptying of water baths, immerse into water bath, squeeze the bellow and point the outlet to a bucket or sink.
Notes: Water temperature must be below 45°C before use.
Product Code: BX0616
Factory Calibration record must be ordered with equipment.
- Factory calibration record.
- The completed calibration record will be enclosed at the rear of the instruction book accompanying the Clifton unit carrying the following information:
Unique record number for traceability. Serial number of the unit. Instrument it was checked against. Calibration temperature and actual sensitivity results. - The measurement of uncertainty ±0.8°C. Ambient temperature 21°C ±3°C.
Notes:
- The calibration record provides a measurement of precision about set point with maximum and minimum sensitivity readings obtained. Precision is defined as “(1) The ability of a measurement to be consistently reproduced” and “(2) The number of significant digits to which a value has been reliably measured”.
- The calibration record does not provide or assures any form of accuracy. Accuracy is defined as “the ability of a measurement to match the actual value of the quantity being measured”.
Product Code : CAL
